This product, please demand the number attached to a terminal, the wire seal separately necessary for not doing it only in a connector on the female terminal side.
As it is a hybrid connector, two kinds of terminals are used.
*4 place of *6 place of 025 type 090 type.
＊There is not the maker setting of the counterpart to fit.


Corresponding terminals separately prepare it as follows.
Please find necessary amount.
In addition, it is available as a spare for the repair.

↓ 025 ↓

■F terminal + wire seal
One "F025WP-SMTS" F terminal and wire seal (it supports an electric wire of AVSS/AVSSB/AVSSC0.3)
■F terminal simple substance
"F025WP-SMTS-wr"
■Wire seal 025TS waterproofing series
"WS7165-0796-025TS"
■Dummy stopper
I use it for the part without the "DP7165-0797-025T S-LGR" terminal

↓ 090 ↓

■F terminal + wire seal
One "F090WP-TS" F terminal and wire seal (it supports an electric wire of AVS0.5-1.25mm2)
■F terminal simple substance
"F090WP-TS-wr"
■Wire seal
"WS7165-0395TS"
■Dummy stopper
"7160-9465HM"

↓ 090 using it for the part without the terminal has with electric wire. ↓
■The terminal with the electric wire is recommended!
"F090WP-TS-AVS05"

There is not the maker setting of the fitting counterpart
