This product is only the F side connector. Please buy F terminal, the wire seal separately.
In addition, the counterpart is not included, too; please buy it separately.

The corresponding terminal separately prepares it as follows.
Please find necessary amount.
It is available as a spare for the repair.

■F terminal simple substance
"F090WP-HM-HW-MT-wr"
■Wire seal
"WS7160-8234HM-MT"
By two points of combinations mentioned above
It supports an electric wire of AVSSB0.5/AVS0.5-1.25.


■Dummy stopper
"7160-9465HM"
I use it for the part without the terminal

■The terminal with the electric wire is recommended!
"F090WP-HM-MT-AVS05"

The fitting counterpart becomes this
◆2P090WP-MT-AL-M-tr (only as for the connector)
